INCONEL alloy 625 & INCONEL alloy 725 – a comparison

09 March 2021

INCONEL alloy 625 & INCONEL alloy 725 – a comparison

We take an in-depth look at these two popular high-performance nickel alloys and compare the specifications and applications.

When you’re looking for a superior material for your next project, a high-performance nickel alloy might be just what you need. However, there are a number of Grades available in the INCONEL range, any of which could suit your requirements and needs.

The flagship INCONEL alloy is INCONEL alloy 625, one of the most versatile materials ever created. With its outstanding corrosion resistance and high strength, it lends itself to a number of applications across a wide range of industries. It’s a hugely popular material of choice that will solve many material problems for design engineers. It’s been doing so for over 50 years now and remains in common usage, which is testament to its quality.

However, if high strength is the priority, INCONEL alloy 725 can be a better fit. It is similar to INCONEL alloy 625, especially in terms of corrosion resistance. However, there are notable differences between the two, which can affect the decision of which to use.

To help you understand the differences and similarities between these two exceptional materials, we compare their main features and properties.

Differences in composition

The reason that INCONEL alloy 625 offers such a wide range of desirable properties lies in its unique make-up. It’s a nickel-heavy alloy, with a minimum 58% of nickel in the blend. It also has chromium (20-23%) and molybdenum (8-10%), plus added niobium (3.15-4.15%).

The niobium combines with molybdenum and distorts the alloy’s atomic matrix, imparting particularly high strength in annealed condition without a specific strengthening heat treatment. The high quantities of nickel and chromium together give the material its incredible corrosion resistance, withstanding highly corrosive elements and environments.

INCONEL alloy 725 shares many of these compositional elements – in fact, on the face of it, they are nearly identical. It retains a high quantity of both nickel (55-59%) and chromium (19-22.5%), plus molybdenum (7-9.50%). As such, the material has similar corrosion resistance to INCONEL alloy 625, making it suitable for use in a broad range of highly corrosive environments.

However, there are subtle differences in the overall composition of the two materials. INCONEL alloy 625 contains small amounts of cobalt and silver, which are not present in the mix for INCONEL alloy 725. INCONEL alloy 725 has a higher amount of titanium (1-1.7% as opposed to 0.4% maximum in INCONEL alloy 625) and iron makes up the balance, rather than having a 5% maximum as per INCONEL alloy 625. These small additions and differences allows for micro precipitates to form during the heat-treating process, which then gives INCONEL alloy 725 its hugely increased strength value.

Comparing strength

INCONEL alloy 625 is a strong nickel alloy. As mentioned, this is down to its composition and the effect of adding niobium. The blend of niobium with molybdenum produces a stiffening effect, negating the need for a precipitation-hardening treatment. For many applications, the high strength inherent in this material is more than adequate. It still outperforms many other nickel alloys in this area.

However, there are occasions when an even higher strength is required, but not at the sacrifice of the outstanding corrosion resistance. INCONEL alloy 625 was introduced and marketed as a solid solution strengthened alloy. It was found to be age hardenable, and over time it was subjected to various tests to study the effects of this. It was found that the age-hardening response was improved significantly by the addition of titanium. This led to the creation of a new alloy – what we know as INCONEL alloy 725 (find out more in this detailed report).

The strength of age-hardened INCONEL alloy 725 is somewhere in the region of twice the strength of annealed INCONEL alloy 625. As INCONEL alloy 725 is strengthened through heat treatment, not through cold working, it retains high ductility and toughness. This strength can be imparted to large and non-uniform sections of material that can’t be strengthened by cold work.

Different applications

The choice of which material to go for often comes down to the intended final application of the alloy.

INCONEL alloy 625 is employed in a wide variety of industries, thanks to its versatility. For example, it is often used in sea-water applications due to its resistance against localised attack, such as pitting and crevice corrosion. It’s also resistant to chloride-ion stress-corrosion cracking. As such, its applications include things like propeller blades for gunboats, submarine propulsion motors, exhaust ducts for Navy utility boats, and sheathing for undersea communication cables.

It is also a material of choice in the aerospace industry, where its high strength, high fatigue and excellent weldability are desirable assets. This includes uses in aircraft ducting systems, engine exhaust systems and fuel lines. Other industry applications include nuclear reactor components, and it’s widely used in chemical processing plants.

INCONEL alloy 725 is also quite variously used across a number of industries, but it is chosen over INCONEL alloy 625 when its exceptionally high strength is required. In the collection of sour gas, for example – where an exceptional resistance to highly corrosive media is required – INCONEL alloy 725 is used for things like hangers, landing nipples, side pocket mandrels and polished bore receptacles.

Like INCONEL alloy 625, INCONEL alloy 725 is also used in the marine industry. Here it is a good choice for things like high-strength fasteners, where its extra strength is needed without sacrificing resistance to corrosion, pitting or crevice attack.

If you’re interested in finding out more about INCONEL alloy 625 or INCONEL alloy 725, as well as the rest of our product lines, please get in touch today to speak to an experienced member of our sales team.
