Super-Duplex stainless steels and their characteristics
Called Duplex because of its mixed microstructure with about equal proportions of ferrite and austenite, Duplex stainless steels are a family of grades, which range in corrosion performance depending on their alloy content. The term “Super-Duplex” was first used in the 1980’s to denote highly alloyed, high-performance Duplex steel with a pitting resistance equivalent of >40 (based on Cr% + 3.3Mo% + 16N%).
With its high level of chromium, Super-Duplex steel provides outstanding resistance to acids, acid chlorides, caustic solutions and other environments in the chemical/petrochemical, pulp and paper industries, often replacing 300 series stainless steel, high nickel superaustenitic steels and nickel-based alloys. The chemical composition based on high contents of chromium, nickel and molybdenum improves intergranular and pitting corrosion resistance. Additions of nitrogen promote structural hardening by interstitial solid solution mechanism, which raises the yield strength and ultimate strength values without impairing toughness. Moreover, the two-phase microstructure guarantees higher resistance to pitting and stress corrosion cracking in comparison with conventional stainless steels. From the introduction of its first-generation, Duplex steel has seen a steady increase in popularity. Recently, the production of highstrength, corrosion resistant super-duplex coil has been implemented in the marine and chemical industries, architecture and mast riggings, wire lines, lifting and pulley equipment and well service strands. In fact, development of wire processing techniques has enabled the production of steel wires down to 1mm in diameter.
The various alloys
Super-Duplex falls under the Duplex stainless steel grouping.
Duplex stainless steels are graded for their corrosion performance depending on their alloy content. Today, modern Duplex stainless steel can be divided into four groups:
- Lean Duplex such as 2304, which contains no deliberate Mo addition;
- 2205, the work-horse grade accounting for more than 80% of duplex usage;
- 25 Cr duplex such as Alloy 255 and DP-3;
- Super-Duplex; with 25-26 Cr and increased Mo and N compared with 25 Cr grades, including grades such as 2507, Zeron 100, UR 52N+, and DP-3W
