ALLOY 601 / INCONEL 601

  • N06601
  • 2.4851

ALLOY 601 / INCONEL 601

INCONEL Alloy 601 is a Nickel based alloy with a high Chromium content (approx. 25wt%) with an addition of Aluminium, which is designed to resist high temperature oxidising atmospheres in the heat treatment of metals and materials. One of the most widely used thermowell sheathing materials and oxygen injection tubes in the metal and glass making industries.

Key properties

(in annealed condition)
Tensile strength: 80.00–110.00
Yield strength: 25.00–55.00
Elongation: 65.00–35.00%
Hardness: 70.00–95.00

Ni

58.00-63.00%

Cr

21.00-25.00%

Al

1.00-1.70%

Cu

1.00% max

Mn

1.00% max

Si

0.50% max

C

0.10% max

S

0.01% max

Fe

Balance

INVENTORY

Product form Size range from Size range to
Alloy 601 pipe 0.5 in 8 in
Alloy 601 tube 12 mm 260 mm
Alloy 601 pipe fittings 0.5 in 8 in
Alloy 601  flanges 0.5 in 8 in
DOWNLOAD DATASHEET

APPLICATIONS

aeroplane

Alloy 601 can be used in a variety of applications

    • Containment rings in gas turbines
    • Process heaters
    • Strippers
    • Air preheaters
    • Catalyst regenerators
    • Combustion chambers in solidwaste incinerators
    • Thermal reactors in exhaust systems of gasoline engines
    • Grid barriers
    • Trays for annealing / carburizing / carbonitriding / nitriding
    • Woven-wire conveyor belts

ABOUT ALLOY 601 / INCONEL 601

The field of use extends to industrial furnace retorts and muffles, baskets, jigs and fixtures, wire annealing tubes which have all been produced in this excellent high temperature material.

Tubing in the alloy has been used for many years in ceramic tile production in the latest designs of roller hearth ovens as the material resists the high temperature firing cycle and the corrosive effects of the glazes and stucco applied to the tiles.

To learn more about our stock of Alloy 601 pipe and tube contact us, or fill in our online quote request form and one of our team will get back to you.

Properties of Alloy 625

DENSITY    8.11 Mg/m3 | 0.293 lb/in³
MELTING POINT 1360-1411°C | 2480-2571 °F

ALLOY 601 MECHANICAL PHYSICAL PROPERTIES

Property 21°C 538°C 649°C 760°C 871°C 982°C 1093°C
Ultimate Tensile Strength /kMPa 689.5 620.5 413.7 234.4 124.1 - -
0.2% Yield Strength /MPa 372.3 331 282.7 179.2 103.4 - -
Minimum Creep 0.0001% per hr,MPa - - - 28.3 13.8 5.2 3
10,000 hr Rupture Strength, MPa - - - 42.7 17.9 8.3 4.3
Coefficient of Thermal Expansion µm/m⁰C - 15.3 16 16.6 17.1 17.6 18.3
Thermal Conductivity /kcal/(hr.m.°C) 9.7 17.3 18.9 20.4 22 23.5 25.1
Modulus of Elasticity/ 105 MPa 2.06 1.75 1.66 1.55 1.42 1.27 1.12

Alloy 601 Specifications

UNS Number N06601
WNR Number 2.4851
Standards ASTM B163, B166, B167, B168, B564, AMS 5715, 5870, B751, B775, B829

Welding Consumables

WELDING ELECTRODES INCONEL 117
FILLERS INCONEL filler metal 82
INCONEL filler metal 601
INCONEL filler metal 617
