ALLOY 825 / INCOLOY 825

  • N08825
  • 2.4858

ALLOY 825 / INCOLOY 825

Alloy 825 / Incoloy 825 is the forerunner of many of the Molybdenum containing nickel iron chromium alloys which have seen service over the past century.

Key properties

(in annealed condition)
Tensile strength: 100.00
Elongation: 45.00%

Ni

38.00-46.00%

Fe

22.00% min

Cr

19.50-23.50%

Mo

2.50-3.50%

Cu

1.50-3.00%

Mn

1.00% max

Ti

0.60-1.20%

Si

0.50% max

Al

0.20% max

C

0.05% max

S

0.03% max

INVENTORY

Product form Size range from Size range to
Alloy 825 pipe 0.5 in 8 in
Alloy 825 tube 12 mm 260 mm
Alloy 825 pipe fittings 0.5 in 8 in
Alloy 825 flanges 0.5 in 8 in
DOWNLOAD DATASHEET

APPLICATIONS

Oil

Alloy 825 can be used in a variety of applications

  • Fuel element dissolvers
  • Sea-water-cooled heat exchangers; offshore product piping systems; tubes and components in sour gas service
  • Heat exchangers, evaporators, scrubbers, dip pipes etc. in phosphoric acid production
  • Air-cooled heat exchangers in petroleum refineries
  • Chemical and Food Processing

ABOUT ALLOY 825 / INCOLOY 825

As the forerunner of many of the Molybdenum containing nickel iron chromium alloys Incoloy Alloy 825 still plays a significant role in heat exchangers for chemical processing,pollution control equipment , oil well and gas gathering pipes – even as clad steel pipe - where resistance to stress cracking or general corrosion to a range of reducing or oxidising acids is required.

To learn more about our stock of Alloy 825 pipe and tube contact us, or fill in our online quote request form and one of our team will get back to you.

Properties of Alloy 825

DENSITY    8.14 Mg/m³ | 0.294 lb/in³
MELTING POINT 1370-1400°C | 2500-2550°F

ALLOY 825 MECHANICAL PHYSICAL PROPERTIES

Property 21°C 93.3°C 148.9°C 204.4°C 315.6°C 371.1°C 426.7°C 537.8°C 684.9°C 982°C
Ultimate Tensile Strength /MPa 585 530 525 515 500 495 485 - - -
0.2% Yield Strength /MPa 240 205 190 180 170 165 155 - - -
Elongation % 30 - - - - - - - - -
Coefficient of Thermal Expansion /µm/m°C ** - 14.1 14.1 14.8 15.3 15.6 15.6 15.8 16 -
Thermal Conductivity /kcal/(hr.m.°C) 9.55 10.578 10.578 11.868 13.224 14.534 14.534 15.652 16.856 -
Modulus of Elasticity / GPa 196 192 192 187 181 174 174 168 162 118

Alloy 825 Specifications

UNS Number N08825
WNR Number 2.4858
Standards ASTM B163, B423, B424, B425, B564, B704, B705, B366, B751, B775, B829

Welding Consumables

WELDING ELECTRODES

Welding Electrode 112
Welding Electrode 686CPT

FILLERS

Filler Metal 625
Filler Metal 686CPT

Download the Alloy 825 data sheet
