ALLOY 800 / INCOLOY 800

Alloy 800 / Incoloy 800 is an Iron nickel chromium alloy with a low carbon content with good strength and resistance to oxidation and carburization to intermediate temperatures.

Key properties

(in annealed condition)
Tensile strength: 54.00–77.00
Yield strength: 13.00–21.00
Elongation: 18.00–23.00%

Fe

39.50% min

Ni

30.00-35.00%

Cr

19.00-23.00%

Mn

1.50% max

Si

1.00% max

Cu

0.75% max

Al

0.15-0.60%

Ti

0.15-0.60%

C

0.10% max

S

0.01% max

INVENTORY

Product form Size range from Size range to
Alloy 800 pipe 0.5 in 8 in
Alloy 800 tube 12 mm 260 mm
Alloy 800 pipe fittings 0.5 in 8 in
Alloy 800 flanges 0.5 in 8 in
DOWNLOAD DATASHEET
MAKE AN ENQUIRY

APPLICATIONS

heat-exchangers

Alloy 800 can be used in a variety of applications

  • Power generation
    • Heat exchangers
    • Muffles
    • Radiant tubes
    • Heat Treat Trays
    • Cracker Tubes
    • Manifolds
    • Food processing
    • Furnace equipment parts





ABOUT ALLOY 800 / INCOLOY 800

The alloy has been used in some steam generation plant due to the resistance to stress cracking however improved materials have tended to supercede the material for this application. Incoloy 800 is a stable austenitic structure which demonstrates good resistance to thermal cycling and finds application in the iris of theatrical spotlights, heater element sheathing, heat exchangers and petrochemical process piping (pigtails).

To learn more about our stock of Alloy 800 pipe and tube contact us, or fill in our online quote request form and one of our team will get back to you.

Properties of Alloy 800

DENSITY    7.94 g/cm³ | 0.287 lb/in³
MELTING POINT 1357-1385°C | 2475-2525°F
MAKE AN ENQUIRY

ALLOY 800 MECHANICAL PHYSICAL PROPERTIES

Property

Imperial

Metric
Density, Ib/in3 (g/cm3 ) 0.287 7.94
Melting Range, °F (°C) 2475 – 2525 1357 – 1385
Specific Heat, Btu/lb•°F (J/kg•°C). 0.11 460
Curie Temperature, °F (°C). -175 -115
Permeability at 200 Oersted (15.9 kA/m)   1.014
Coefficient of Expansion, 10-6 in/in•°F (µm/m•°C)
70-200°F (20-100°C)
 7.9 14.4
Thermal ConductivityA , Btu•in/ft2•h•°F (W/m•°C) 80 11.5
Electrical ResistivityA , ohm•circ mil/ft (µΩ•m). 595 0.989

Alloy 800 Specifications

UNS Number N08800
WNR Number 1.4876
Standards ASTM B 163, A 240, B 366, B 407 – B 409, A 480, B 514, B 515, B 564, B 751, B 775, B 829

Welding Consumables

WELDING ELECTRODES INCOWELD A
FILLERS 82
